Sovelia Routing What's new

Find the release news and notes of Sovelia Routing on this page going back few versions.

What's New and Release Notes

Issues solved

  • [SOVR-289] - Inventor standard addins not loading.

Issues solved

  • [SOVR-274] - Issue continuing from Collar
  • [SOVR-284] - Library elbow issue

Enhancements & Changes

  • [SOVR-269] - Default Ribbon
  • [SOVR-272] - Autoset Templates in Settings/Files
  • [SOVR-273] - Default installed Resources updted
  • [SOVR-276] - Reverse buttons in Copy

What's new

  • [SOVR-155] - Pipe Support place - release

Issues solved

  • [SOVR-270] - Vaulted components getting dirty when placing

New Features

  • [SOVR-155] - Pipe Support place - Beta
  • [SOVR-261] - Create Centreline creation at spool level

Issues solved

  • [SOVR-240] - Cannot join pipes when 2nd pipe contains reducer
  • [SOVR-245] - Flange reverses when running Edit Route.
  • [SOVR-256] - Issue with split and pipes reversed in edit.
  • [SOVR-258] - Issue with join when Weld gaps are involved

Enhancements & changes

  • [SOVR-255] - In create/edit keep flange when changing size

Issues solved

  • [SOVR-220] - Aim At Point from elbow, angle value should always be elbow angle (sometimes 180-angle)
  • [SOVR-223] - Cutback the elbow that is closest (rounded up)
  • [SOVR-230] - Suggest a possible fast route when 90 deg elbow is not possible
  • [SOVR-233] - Cutback 45 deg elbow not working
  • [SOVR-235] - Library components are not recognized when editing Route

Enhancements & changes

  • [SOVR-183] - Enhancement of Delete command
  • [SOVR-227] - Delay graphic updates when typing in textboxes
  • [SOVR-228] - Link to license.symetri.com for administrators
  • [SOVR-229] - When clicking on active component don't do next
  • [SOVR-231] - Color elbow red if angle exceeds elbow angle
  • [SOVR-236] - Hide pipe dimensions which do not have elbows
  • [SOVR-237] - Local numbering scheme: Automatically increase sequence value when name is occupied

Enhancements & changes

  • [SOVR-225] - Added conditional statement in export.

Issues solved

  • [SOVR-212] - Cannot create 180 degrees bends
  • [SOVR-213] - Change style is reading in incorrect data
  • [SOVR-214] - Failed writing to standard properties when Inventor is in another language than English
  • [SOVR-221] - Delete precious versions in "Programs and Features" when updating

Enhancements & changes

  • [SOVR-206] - Highlight pipes that will be exported
  • [SOVR-215] - Export enhancement, non-native extruded pipes
  • [SOVR-216] - Add About dialogue and show version installed¬†
  • [SOVR-217] - Spec editor: Increase tolerance to mapping assistant for thickness and diameter

Issues solved

  • [SOVR-129] - Edit "Custom" Collar resets the height.
  • [SOVR-138] - MSI package creation for Sovelia Routing
  • [SOVR-165] - Issue with reducer if click to close to either start or end of straight.
  • [SOVR-166] - Split command, destroys routes when crashing.
  • [SOVR-167] - Stretch pipe removes special elbows.
  • [SOVR-168] - Join not working (mmcfp)
  • [SOVR-169] - Change style not working
  • [SOVR-170] - Focus issue
  • [SOVR-171] - Issue with placing reducer at start/end of pipe.
  • [SOVR-172] - Spec Editor, Elbow view is empty in v1.0.2
  • [SOVR-173] - Change style and custom elbow not being overridden (wrong elbow is used).
  • [SOVR-189] - Not possible to route bended pipes
  • [SOVR-190] - Not possible to demote other components than SR Spools
  • [SOVR-192] - Add Collar in Spec Editor do not allow, "," or "." in the cells.

Enhancements & changes

  • [SOVR-100] - Rewrite settings
  • [SOVR-150] - Decrease load time for pipe data window
  • [SOVR-151] - Decrease load time for loading of pipe
  • [SOVR-180] - Migrate library path
  • [SOVR-143] - Segment length/XYZ length
  • [SOVR-144] - Improve collar and holes
  • [SOVR-149] - Decrease load times
  • [SOVR-193] - User wants to configure export-files path to %SpoolPath%\%SpoolName%\
  • [SOVR-195] - Direct help button in Ribbon to sovelia.com
  • [SOVR-198] - Change "Custom Angle" to "Can Cutback" or similar.
  • [SOVR-199] - Move Display diameter when adding a pipe family to first column.
  • [SOVR-200] - Collar column "Length" should be "Height"
  • [SOVR-201] - Create new route, spool name preview is awful :)
  • [SOVR-204] - Remove white background in naming scheme dialogs
  • [SOVR-205] - Rename, Spec Editor Window Title

Issues solved

  • [SOVR-159] - XYZ list incorrect

Enhancements & changes

  • [SOVR-145] - Bend table name on drawing (remove file extension from header)
  • [SOVR-146] - Drawing template file format, add .dwg
  • [SOVR-148] - Setting for showing/hiding Bend Radius in Bend Table

Issues solved

  • [SOVR-120] - Change style: Switching between bended and welded specs.
  • [SOVR-121] - Create: Insertion length
  • [SOVR-122] - Join, different issues
  • [SOVR-124] - Special elbow: Index out of range
  • [SOVR-125] - Insert any with weld gaps
  • [SOVR-133] - Space should reverse start in create pipe.
  • [SOVR-134] - Special elbow crash when ending/starting with elbow?
  • [SOVR-135] - Assembly Tee can not be modified
  • [SOVR-139] - Graphical issue, flange not shown in correct position after change

Enhancements & changes

  • [SOVR-96] - Only show Elbows for active spec in Spec Editor
  • [SOVR-105] - Promote/Demote highlight model when selecting a row.
  • [SOVR-116] - Add filter to elbow selection
  • [SOVR-117] - Finalize license implementation
  • [SOVR-131] - Auto-set weld gap for start/end edge.
SOVELIA ROUTING - Giving you the means to enjoy pipe design
